AUTOMOBILE ALTERNATOR 2112.3701

PRODUCT REMOVED FROM MANUFACTURING



Automobile alternator 2112.3701
General information
Specifications
Speed current characteristic of the generator set
Dimensional drawing



General information:

Automobile alternator 2112.3701 is purposed for provision of the customers with electric power in different mode of operations of the engine of the automobiles VAZ-2110, VAZ-2111, VAZ-2112, VAZ-2108?, VAZ-2109? and others.

Alternator 2112.3701 is performed in compact constructive performance. The direction of rotation of the shaft of generator from the drive side is right. Alternator is produced in a single climatic design I2.1 in accordance with GOST 15150 for internal market and for export. The operating mode of the alternator - S1 in accordance with GOST 3940.

The warranty period of exploitation is 3 years from the date of commissioning or from the date of sale in retail commercial network. The date of production is marked on the case of the item.
  up



Specifications:

Rated voltage, V
14,0
  Maximum rectified current, no more than, A
80,0
  Power capacity, kW
1,12
  Mass, no more than, kg
4,9

  up



Speed current characteristic of the generator set:

Speed current characteristic of the generator set 2112.3701

  up



Dimensional drawing:

Dimensional drawing of automobile alternator 2112.3701
